| Overview | KC 640×512 Series |
| Movement parameters |
| Detector type | Vanadium oxide uncooled infrared focal plane detector |
| Resolution | 640×512 |
| Pixel Pitch | 12um |
| Spectral Band | 8-14μm |
| NETD | ≤40mK |
| Frame rate | 50Hz |
| shutter | Automatic shutter correction |
| Lens Parameters |
| focusing | Adjustable focus |
| aperture | 1.0 |
| Lens millimeters | 9mm/13.55/19/25/35/55/other |
| FOV(H*V) | 48.9°×39.1°/~ |
| Detection distance |
| people | 1200mm |
| vehicle | 2650mm |
| Recognition distance |
| people | 350mm |
| vehicle | 700mm |
| Function |
| Pseudo color | White heat |
| Standard | PAL |
| type of output | CVBS |
| Power supplyvoltage | 4.5-18V |
| power | 1000mw |
| working temperature | -40℃~+80℃ |
| Storage temperature | -50℃~+85℃ |
| size | 21*21MM |
| weight | 22g |
