| Overview | KA 384×288 Series |
| Movement parameter |
| Detector Type | Vanadium Oxide Uncooled Focal Plane Arrays |
| Resolution | 384X288 |
| Pixel Interval | 12um |
| Response band | 8-14μm |
| NETD | ≤40mK |
| Refresh Rate | 25Hz |
| Shutter | Automatic shutter correction |
| Lens parameter |
| Focusing | Support |
| Aperture | 1.0 |
| Lens millimeters | 9.1mm | Other customize |
| FOV(H*V) | 29.3°×22° | ~ |
| Other |
| Palettes | White heat/Black heat/Iron red/Anti-iron red/Red heat/Anti-red heat/Greyishyellow/Anti-greyish yellow/Blueish red /Anti-blueish red /Greyish red/Anti-greyish red |
| System | PAL |
| Output type | CVBS |
| Supply voltage | 4.5-18V |
| Power dissipation | 1000mw |
| Operating temperature | -40℃~+80℃ |
| Storagetemperature | -45℃~+85℃ |
| size | 28*28*41.5MM |
| Weight | 55.2g |
